Explanation of the core structure of the roadblock machine's sturdy and anti-collision function: main frame, hydraulic drive system, electrical control system

Roadblocks are equipment for controlling the passage of vehicles on roads. Roadblocks can be divided into: flip roadblocks (with or without tips), anti-terrorist roadblock walls (with or without tips), and simple roadblocks. The hydraulic drive part can be equipped with vehicle detectors, ground sensing coils, infrared sensors, and can be used in conjunction with gate control systems or alone. It can be used in conjunction with gate control systems or alone; it is specially designed and developed to prevent non-permitted vehicles from forcibly entering sensitive areas, and has high practicality, reliability and safety; it is suitable for vehicle channel control in special places such as customs, border inspection, prisons, vaults, nuclear power plants, military bases, key government departments, airports, logistics, ports and docks.

Main frame: The roadblock machine is mainly composed of a flip body or a lifting body and a machine base (anti-collision teeth can be installed according to customer needs). The whole machine is a steel structure, welded with national standard 20mmA3 carbon steel plate and channel steel, with high load-bearing and anti-collision capabilities; there are no electrical appliances or circuits in the machine body, which is waterproof and safe. The device is buried in the designated position of the lane or gate, and the passage of vehicles is restricted by the instructions of the on-duty personnel.

Hydraulic transmission station: The hydraulic transmission station is mainly composed of an oil tank, a manual oil pump, a full set of hydraulic solenoid valve groups, a high-power motor, an oil pump, an oil cylinder, an oil gauge, a high-pressure hydraulic oil pipe, etc. It is the power source of the entire roadblock system. The device is installed on one side of the roadblock machine and is used in conjunction with the roadblock machine (the rising and falling speed can be changed through the regulating valve). The baffle can be manually lowered or raised manually during a power outage.

Electronic control system: Automatic electronic control part: adopt single-chip PLC/MCU control, leakage switch, contactor with no contact noise and high life, etc., precise starting time setting (the impact force generated after the oil cylinder stroke is in place increases the service life of the oil cylinder).

The roadblock machine is mainly composed of a flip body, a lifting body, and a machine base, with anti-collision teeth of 35*90mm, mandatory interception; there are channel steels of national standards 16 and 12 around and in the middle, and the load-bearing and anti-collision capabilities are strong; the minimum connection is 3~8 50MM rotating shafts, easy and flexible operation, hydraulic transmission, smooth and fast movement, low noise, strong traffic capacity, no electrical appliances and lines in the machine body, waterproof, safe and reliable.
